Description
REPLACEABLE SLEEVE STABILIZER
replaceable sleeve stabilizer consists of an integral mandrel and a sleeve. One mandrel series can be equipped with different size of sleeve for several hole sizes. The sleeves are easily changed on the rig floor, either when changing hole size or changing the type of wear surface to match drilling conditions.
When ordering please specify:
Mandrel series and sleeve O.D.;
String or near bit application;
Top and bottom connection;
Hardfacing type.
Specifications – Sleeve
| Sleeve | Mandrel | Overall Length(mm) |
Product Code | ||||
|---|---|---|---|---|---|---|---|
| Length(mm) | O.D.(mm) | Blade Qty | I.D.(mm) | Fishing O.D.(mm) | Connection | ||
| 380 | Φ155 | 4 | Φ44 | Φ121 | NC38 | 1638 | W0900301 |
| 380 | Φ157 | 4 | Φ44 | Φ127 | NC38 | 1638 | W0900401 |
| 500 | Φ214 | 4 | Φ71 | Φ165 | NC50 | 2013 | W0901001 |
| 500 | Φ220 | 4 | Φ71 | Φ165 | NC50 | 2013 | W0901201 |
| 500 | Φ255 | 4 | Φ71 | Φ165 | NC50 | 2013 | W0901601 |
| 500 | Φ304 | 4 | Φ76 | Φ203 | 6 5/8 REG | 2000 | W0902001 |
| 500 | Φ310 | 4 | Φ76 | Φ203 | 6 5/8 REG | 2000 | W0902101 |
| 500 | Φ313 | 4 | Φ71 | Φ165 | NC50 | 2013 | W0902103 |
| 500 | Φ371 | 4 | Φ71 | Φ197 | 6 5/8 REG | 2013 | W0902201 |
| 500 | Φ374 | 4 | Φ71 | Φ203 | 6 5/8 REG | 2013 | W0902203 |
| 520 | Φ405 | 4 | Φ76 | Φ241 | 7 5/8 REG | 2045 | W0902301 |
| 520 | Φ430 | 4 | Φ76 | Φ241 | 7 5/8 REG | 2045 | W0902401 |
| 520 | Φ444 | 4 | Φ76 | Φ241 | 7 5/8 REG | 2045 | W0902501 |
| 600 | Φ558 | 4 | Φ76 | Φ241 | 7 5/8 REG | 2130 | W0902701 |
| 690 | Φ711 | 5 | Φ76 | Φ241 | 7 5/8 REG | 2210 | W0903401 |
Our company has been in the oil & gas drilling equipment industry for over more years, We are here to serve all your drilling equipment needs.
