API 16A Sucker Rod BOP

Description

API 16A Sucker Rod BOP

The Sucker Rod BOP is mainly used to seal the sucker rod in the process of lifting or lowering the sucker rod in oil Wells, so as to effectively prevent the occurrence of blowout accidents. Manual Dual Ram Sucker Rod BOP is equipped with blind ram and semi-sealed ram each one. The upper end of the BOP is equipped with a rod sealing unit. When the sealing rubbers in the rod sealing unit need to be replaced, but the rod in the well, the semi-sealed ram can seal the rod and annulus to achieve the purpose of well sealing. When there is no sucker rod in the well, the wellhead can be closed with the blind ram.
It is simple in structure, easy to use and maintain, small in size, light in weight, simple and reliable in operation. It is mainly composed of shell, end cover, piston, screw, ram assembly, handle and other parts.
API 16A 1-1/2 inch (φ38) sucker rod bop 1500-3000PSI EUE
sucker rod bop to prevent the leakage of oil and gas in the recovery operation control device, can guarantee the well-flushing, sand washing, fracturing downhole operation smoothly. By changing different valve core, and can meet the needs of all kinds of rod seal. Product design is reasonable, simple structure, convenient operation, reliable sealing, long service life and is one of indispensable tools in oil field work.
Main technical parameters:
1, the maximum working pressure: 10.5 MPa (1500 psi)
2, is suitable for sucker rod specifications: 5/8-11/8 (16 to 29 mm) in
3, the upper and bottom nipple: 3 1/2 UP TBG
Product Paramenters
SIZE (in)
ROD D.(in)
THREAD D. (in)
LENGTH (ft)
OUTSIDE DIAMETER OF PIN SHOULDER(mm)
LENGTH OF PIN(mm)
LENGTH OF WRENCH SQUARE(mm)
WIDTH OF WRENCH SQUARE(mm)
5/8″
5/8″
15/16
2 4 6 8 10 25 30
31.75
31.75
≥31.75
22.23
3/4″
3/4″
2001/1/16
38.1
36.51
25.4
7/8″
7/8″
2001/3/16
41.28
41.28
1″
1″
2001/3/8
50.8
47.63
≥38.10
33.34
1-1/8″
1-1/8″
2001/9/16
57.15
