Description

3-position 5-Way Valve (35HR6-L10-F)

三位五通阀 3-position 5-Way Valve (35HR6-L10-F)
In repair kit维修包	(Item)序号	图号(Part No.)	名称(Description)	数量Qty
	1	JY-35F-10	右端盖Right End	1
	2	JY-35F-5	套 Valve Sleeve	2
▲	3	GB/T3452.1-1992 32×3.55	O形密封圈O-Ring	2
	4	JY-35F-6	阀体 Valve Body	1
▲	5	GB 1235-76 22X2.4	O形密封圈O-Ring	2
	6	JY-35F-7	中间阀套 Inter Valve Sleeve	2
▲	7	GB 1235-76 28X3.5	O形密封圈O-Ring	4
	8	JY-35F-4	挡板Retain plate	1
	9	JY-35F-3	弹簧 Spring	1
	10	JY-35F-2	弹簧Spring cap	1
	11	JY-35F-10	左端盖Left End	1
	12	GB/T 5780-2000 M5x40	内六角螺栓Screw	8
	13	JY-35F-9	销轴 Pin	1
	14	GB95-20004	平垫圈 Flat Washer	1
	15	GB/T91-2000 1.5×10	开口销Pin	3
	16	CA-10B	手柄球Handle	1
	17	JY-35F-12	手柄杆Handle Pin	1
	18	JY-35F-11	销轴Pin	2
	19	JY-35F-13	连接片 Connecting Sheet	2
▲	20	GB/T 3452.1-199212.5*16	O形密封圈O-Ring	4
	21	JY-35F-8	阀芯 Valve Core	1
	22	GB/T119.1-20003X16	圆柱销 Pin	1
	23	3.4TQF-00-06	阀杆 Valve Stem	1
