Gasoline engine Sewer Drain Cleaning Machine


Gasoline engine Sewer Drain Cleaning Machine

Model: DP-50/180
Rate Pressure: 180bar; Water flow: 50 L/min
Water flow: 50 L/min
Electric power:


Name    Details
Model    DP-50/180
Speed    1480 rpm
High pressure pump    Italy COMET Brand;
Rate Pressure    180 bar / 2600 psi
Water flow    50 L/min
Plunger dia.    28mm
Gasoline engine    24HP, double-cylinder, HONDA Brand, GX690


  2. Characteristic:


1. Pump Head: Cooper material, High pressure resistant, high tem. resistant;

2. Plunger: Ceramic material, wear-resisting, corrosion resistance.

3. High pressure pump: Three plunger reciprocating, forced lubrication;

4. Pressure Regulating valve: Alloy valve spool and Alloy valve seat;

5. Gasoline: HONDA Brand; With high quality and long working time.


  3. Maine Machine include:


Name    Details Quantity
High pressure pump    180bar; 50 L/min; Italy COMET Brand 1 set
Pressure regulating valve    Details0-180bar can be adjust 1 pc
Pressure gauge    Details Details Data 0-600bar 1 pc
Gasoline engine    Details 24HP; HONDA Brand; Model: GX690 1 set
Fuel Tank    Volume 100L 1 set
Storage Battery    12V 45Ah 1 set
Connect belt    Connect the pump with engine 3 pc
Ball Valve    Control the nozzle working 1 set
Y-type Filter    Water inlet filter 1 set
Hose Reel    To hold the high pressure hose 1 set
Movable chassis    With 4 small wheels, easy to be moved 1 set


  4. Accessories:




High pressure hose    DN13; Bear Pressure 22Mpa
Sewer cleaning nozzle    DN40 Mul-ti hole cleaning nozzle
Water spray gun    For surface dirt cleaning
Fan-shaped nozzle    Connect with the water spray gun


  5. Sewer cleaning machine has three driven type for your choose:

Electric motor drive (Model: 50/150)

Gasoline engine drive (Model: 50/180)

Diesel engine drive ( Model: 50/220)


  6. Application:

1. Municipal pipeline cleaning;

2. Housing estate, hotel, restaurant, factory sewer pipe cleaning;

3. Ground surface cleaning, car cleaning, wall surface dirt cleaning, etc.


  7. Packing and shipping
