Description
QW Series of drill pipe air slips features auto-clamping and auto-scraping fuctions during tripping operation. It is an ideal tool and applicable for all kinds of rotary tables. The slips owns such advantages: convenient installation, simple operation, safe and reliable, highly automated, and can improve tripping speed. Technical specification meets standard SY5049.
Product Paramenters
|
Model
|
QW-175
|
QW-205(520)
|
QW-275
|
QW-375
|
|
|
Suited for which rotary tables
|
ZP175
|
ZP205(ZP520)
|
ZP275
|
ZP375
|
|
|
Working pressure
|
MPa
|
0.6—0.9
|
|||
|
psi
|
87 -130
|
||||
|
Effective clamping length
|
mm
|
350
|
420
|
420
|
420
|
|
in
|
133/4
|
161/2
|
161/2
|
161/2
|
|
|
Rated load
|
kN
|
2250
|
2500
|
2500
|
2500
|
|
Slip extenstion height
|
mm
|
< 300
|
|||
|
in
|
<12
|
||||
|
Pipe range
|
in
|
41/2″,5″,51/2″
|
|||
|
Size
|
mm
|
φ443×584
|
φ520×584
|
φ697×581
|
φ481×612
|
|
in
|
φ17.5×23
|
φ20.5×23
|
φ27.5×23
|
φ19×24
|
|
|
Weight
|
kg
|
440
|
620
|
1020
|
920
|
|
lb
|
970
|
1370
|
2250
|
2030
|
|
Type QW Pneumatic Clip is an ideal well-head mechanized tool with double functions, it can automatically handle the drill pipe when the drilling rig is running in hole or does pipe wiping when the drilling rig is pulling out of hole. It can accommodate different kinds of drilling rig rotary table. And it features convenient installation, easy operation, complete functions, high automation, low labor intensity, and can improve the drilling speed.
Our company has been in the oil & gas drilling equipment industry for over more years, We are here to serve all your drilling equipment needs.
